Motor Replacement (Snack Trays)

When replacing the motor on your plastic tray, you will need to remove the tray first.

This video covers the procedure to replace motors on the snack tray of your vending machine. It helps the viewers understand the smooth ejection of the old motor and the prerequisites required while fitting the new motor into the machine.

Begin by sliding the motor cover off of the tray. Lift the motor up off the tray when pulling out the coil coupler. Make sure the wires from the old motor are connected correctly to the new motor. It is recommended that you use a set of needle nose pliers to remove the wires from the motor. Slide the new motor off the tray and place the new motor on the tray. The motor specific color wire is connected on the bottom connector. The red-white common wire is at the top. Lift the motor up off the tray when pushing in the coil coupler

For more assistance please see our other tray tutorial videos, including how to install a plastic tray. We also have a coils and motors video section.

If you need parts visit our online store to find trays, motors, coils and other vending machine parts.

For additional support, visit our Help Center.

Language: English
Product Type:Trays
Difficulty: easy
Duration: 5-15 Minutes
Models: 3535, 3565, 3566, 3573, 3574, 3575
